Подробное описание:
intel®Pentium®D,Pentium®4processor,SocketT(LGA775)
-FSB800/533MHz
-400/333MHz DDRx2DIMMs,Max2GB
-5.1channelAudio,AC’97interface(Realtek)
-10/100MLAN(Broadcom)
-8USB2.0/1.1ports
Processor: Support Socket T (LGA775) Intel®
, Pentium® 4 processors
Chipset: SiS 661FX + 964
Front Side Bus: 800 / 533 MHz
Memory: Support Max. 2GB Single Channel 400MHz / 333MHz / 266MHz DDR x2 DIMMs
VGA on Die: Integrated SiS Mirage™ Graphics
Expansion Slots: 1x AGP 8X, 3 x PCI slots
IDE: 2 x ATA 133
Serial ATA(SATA)/RAID: 2 x Serial ATA with RAID 0, 1, JBOD
Audio: 5.1 channel, Realtek ALC653 (AC’97 interface)
LAN: 10 / 100M LAN, Broadcom AC131KML
IEEE1394: N/A
Back Panel I/O Ports: 1 set 5.1 channel Audio jack (3 jacks)
1 x VGA
1 x PS/2 keyboard
4 x USB 2.0/1.1 ports
1 x PS/2 mouse
1 x RJ45 port
1 x parallel port
1 x COM port
Internal I/O Connectors: 2 x USB 2.0 headers; support 4 ports
1 x S/PDIF out header
1 x CD-IN header
1 x COM2 header
1 x IrDA header
1 x speaker header (reserve only)
1 x Front audio header
1 x buzzer
1 x Intruder
1 x AUX IN
1 x Front panel header
BIOS Features: 4Mb flash ROM, PnP1.0a, DMI 2.0, WfM 2.0, SMBIOS 2.3, ACPI 1.0b,
Support CD: Chipset Driver, Device Driver, RAID Driver, DirectX 9.0C, Adobe Reader6.0,
SuperUtilities, Norton Internet Security
Standards/Manageability: PCI 2.3, USB2.0; WfM 2.0, DMI 2.0
Special Features: STR (Suspend-to-RAM); STD (Suspend-to-Disk); SuperSpeed, SuperBoot,
SuperBIOS-Protect, SuperRecovery, SuperStep, SuperLogo, SuperUpdate
Form Factor: Micro ATX (9.6" x 8.3")  |
